Profils Systèmes presents its new Cuzco® 713 aluminium casement window with 45° or 90° cut

15 january 2017 - Product News

Cuzco® 713 is once again adding to this range with a new aluminium casement window with very high, progressive thermal values in 45° or 90° cut. With its 70 mm fixed frame, Cuzco® 713 has just completed its range with a new 45° or 90° cut version.

Optimised progressive thermal values are available up to Uw:1.3 W/m2K with Ug: 1.1. double glazing

Thermal bridge standard THERMIQUE TH:
Uw= 1,6 W/m2K – Sw= 0,46 – Tlw= 0,58

Thermal bridge standard BOUCLIER TH+:
Uw= 1,4 W/m2K – Sw= 0,46 – Tlw= 0,58

Thermal bridge standard BOUCLIER TH Max:
Uw= 1,3 W/m2K – Sw= 0,46 – Tlw= 0,58

For a window with 2 leaves L1530 x H1480mm – Ug: 1.1 avec Swisspacer ULTIMATE spacer

With invisible hinges available as an option, the Cuzco® casement style opens up new design possibilities and makes this window even more discreet.

With its slim, straight, reduced profiles, Cuzco® 713 fits perfectly into the Cuzco® collection with its 70mm fixed frames.

Windows, French windows, tilt-turn and hopper styles, Cuzco® 713 offers multiple possibilities and is available with a European slot, a 16mm slot, traditional fixed frame and monoblock.

Design, security and accessibility are the strong points of this range with:

  • Key locking option
  • Disabled access sill
  • 3 hinge options: slide-in, screw-in or invisible
  • Reduced aluminium section 84.9 mm on fixed frame/opening sections
  • Cental mullion up to 86,6 mm
  • Cuzco® 712 is available in all Profils Systèmes’ exclusive colours: Terra Cigala®, Mahoé®, Eclat Métalliques® , Profils Color®  et Terre de Matières®.
  • Shades are guaranteed for up to 25 years.

Cuzco® 713 will be available in Avril 2017!
